Genset specs
Explore specs of each of our 3 genset models.
| 20 KVA | 50KVA |
 |
 |
| 20 kVA / 16 kWe (Prime) | 50 kVA / 40 kWe (Prime) |
| 415 VAC / 50 Hz | 415 VAC / 50 Hz |
| Isuzu 4LE1 | Isuzu 4BG1T |
| Interim Tier-4 / Stage-IIIA | Tier-2 |
| 78 L | 160L |
| 51 dB(A) | 57 dB(A) |
| 1 x 415V 20A (3PH) 3 x 240V 15A (1PH) |
1 x 415V 50A (3PH)
1 x 415V 32A (3PH) 1 x 415V 20A (3PH) 3 x 240V 15A (1PH) |
| 1440 x 780 x 1140 mm | 2000 x 950 x 1430 mm |
| 699 kg (dry) | 1431 kg (dry) |
| 27.8 / 0.80 | 69.6 / 0.80 |
| Rotating Field, Brushless 3-Phase Synchronous Alternator, 4-Pole | Rotating Field, Brushless 3-Phase Synchronous Alternator, 4-Pole |
| 3-Phase, 4-Wire / F | 3-Phase, 3-Wire / F |
| Self Excitation (Brushless) | Self Excitation (Brushless) |
| Engine specs | |
| Water Cooled, 4-Cycle Diesel Engine | Water Cooled, 4-Cycle Diesel Engine |
| Isuzu 4LE1 / 4 | Isuzu 4BG1T / 4 |
| 2.2 L | 4.329 L |
| 19.1 kW @ 1500 RPM | Direct Injection, Turbocharged |
| Swirl Chambered Indirect Injection, Naturally Aspirated | Direct Injection, Turbocharged |
| Radiator | Radiator |
| 8.2 L (50-50% Water-Glycol) | 17.0 L (50-50% Water-Glycol) |
| Forced Lubrication | Forced Lubrication |
| 8.8 L | 13.2 L |
| Diesel Fuel (ASTM No. 2-D) only | Diesel Fuel (ASTM No. 2-D) only |
| 5.2 L/hour (approx.) | 11.8 L/hour (approx.) |
| Electric Start | Electric Start |
| 12 V – 2.0 kW | 24 V – 4.5 kW |
| 12 V – 20 A | 24 V – 20 A |
| 75D31R / 1-Pole | 95D31R x 2 / 1-Pole |
 |
|
